超濾設備Ultrafiltration system：

超濾是一-種能將 溶液進行凈化和分離的膜分離技術。超濾膜系統是以超濾膜絲為過濾介質，膜兩側的壓力差為驅動力的溶液分離裝置。超濾膜只允許溶液中的溶劑(如水分子)、無機鹽及小分子有機物透過,而將溶液中的懸浮物、膠體、蛋白質和微生物等大分子物質截留,從而達到凈化和分離的目的。

Ultrafiltration is a membrane separation technique that can let the solution to be purified and isolated. The ultrafiltration membrane system is a membrane separation techinque basis on the wire ultrafiltration membrane as the filter medium, the pressure difference on both sides of the membrane as the driving force. Ultrafiltration membrane only allows solution of the solution of the solvent(water molecules), inorganic salts and small organic molecules to get through, But the suspended solids of solution, colloids,proteins and micro-organisms

and other macromolecules can be intercepted, so as to achieve the purpose of purification and separation.

超濾膜被大量用于水處理工程。超濾技術在反滲透預處理、飲用水處理、中水回用等領域發揮著越來越重要的作用。

超濾技術在酒類和飲料的除菌與除濁,藥品的除熱原以及食品及制藥物濃縮過程中均起到關鍵作用。

Ultrafiltration membrane is widely used in water treatment engineering. Ultrafiltration technology play an increasingly important role

in reverse osmosis pretreatment, water treatment, water reuse, and other fields. Ultrafiltration tecchnology play a key role in removing

bacteria and turbididy from liquor and beverages, removing the pyrogen of the pharmaceytical, and in the process of food and drug

concentration.

工作原理Working principle：

超濾是一一種以篩分為分 離原理,以壓力為推動力的膜分離過程,過濾精度在0.005-0.1μm范圍內,可有效去除水中的微粒、膠體、細菌、熱源及高分子有機物質?？蓮V泛應用于物質的分離、濃縮、提純。超濾過程無相轉化,常溫下操作,對熱敏性物質的分離尤為適宜，并具有良好的耐溫、耐酸堿和耐氧化性能,能在60°C-下, PH為2- 11的條件下長期連續使用。

Ultrafiltration is a membrane separation process which is using screening as separation principle, using pressure-driven as the driving

force,to keep the filtering accuracy in the range of 0.005 -0.01, which can remove particles, colloids, bacteria, heat and organic polymer material

from the water effectively. Ultrafiltration can be widely used in material separation, concertration and purification. The ultrafiltration process

without phase inversion, operating at room temperature, is particularly suitable for the separation of heat-sensitive material, and has good heat

resistance, acid and alkali resistance and oxidation resistance, also can be workable in long-term and continuous service under the conditions of

temperature below 60~C, pHis2-11.

產品優點Advantage：

1、系統回收率高,所得產品品質優良，可實現物料的高效分離、純化及高倍數濃縮。

2、處理過程無相變,對物料中組成成分無任何不良影響，且分離、純化、濃縮過程中始終處于常溫狀態,特別適用

于熱敏性物質的處理,完全避免了高溫對生物活性物質破壞這一弊端,有效保留原物料體系中的生物活性物質及營養成

分。

3.系統能耗低,生產周期短,與傳統工藝設備相比,設備運行費用低,能有效降低生產成本,提高企業經濟效益。

4、系統工藝設計先進,集成化程度高,結構緊湊，占地面積少,操作與維護簡便,工人勞動強度低。

5、系統制作材質采用衛生級管閥，現場清潔衛生,滿足GMP或FDA生產規范要求。

1.The system's recovery rate is high, the products are with good quality, the system can realize high eficient separation and multiple

enrichment of the material.

2.No phase transition in process, No adverse effects to the composition of materials, and the separation, purification and cnrichment

process is always under normal temperature, especially suitable for the processing of heat sensitive material,completely avoid the

disadvantages of high temperature bring damage to bioactive substances, effcetively retain biological active substances in the raw material

system.

3.Low energy consumption in the system, short production cycle, comparing with the traditional process equipment, the equipment

operation cost is lower, can reduce the production cost effectively, improve enterprise economic benefits.

4.Advanced design of system process, high integrated degree, compact structure, economic Space Occupation, easy operation and

mainterance, low labor intensity,

5.Adopt the tube valve with health level in material system, the clean and health can meet the requirements or the FDA or GMP

standard.
